CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Compact Belt Drive (TCH/V) Series
Rev.: July 25, 2017
22
ClimateMaster Water-Source Heat Pumps
TCV Field Conversion of Air Discharge
Overview
-
Vertical units can be fi eld converted between
top and straight (side) and back (end) discharge using the
instructions below.
Preparation - Place in a well-lighted area. Conversion
should only be attempted by qualifi ed service technicians.
WARNING!
WARNING! To avoid possible injury or death due to
electrical shock, open the power supply disconnect switch
and secure it in an open position during installation or
conversion.
