ClimateMaster Water-Source Heat Pumps
TCH Physical Data
TCH072 TCH096 TCH120
Weight - Operating (lbs) [kg] 586 [265.8] 644 [292.1] 698 [316.6]
Weight - Packaged (lbs) [kg] 626 [283.9] 684 [310.3] 738 [334.8]
Weight - Corner - Control box/Compressor side (lbs) [kg] 235 [106.6] 254 [115.2] 271 [122.9]
Weight - Corner - Compressor side (lbs) [kg] 101 [45.8] 120 [54.4] 137 [62.1]
Weight - Corner - Blower side (lbs) [kg] 180 [81.6] 190 [86.2] 200 [90.7]
Weight - Corner - Air Coil side (lbs) [kg] 70 [31.8] 80 [36.3] 90 [40.8]
TCH072-120 Corner Weights
Unit with WSE Option
Model 072 096 120
Compressor Quantity Scroll
Number of Circuits (Compressors) 2
Factory Charge HFC-410a (oz) [kg] per
circuit
60 [1.70] 76 [2.15] 80 [2.27]
Blower Motor
Blower Motor Quantity 1
Standard Motor (hp) [kW] 1 [0.75] 2 [1.49] 3 [2.24]
Large Motor (hp) [kW] 2 [1.49] 3 [2.24] 5 [3.73]
Blower
No. of Blowers 1
Blower Wheel Size D x W (in) [cm] 12 x 12 [30.48 x 30.48]
Water Connection Size
FPT (in) [mm] 1-1/4" [31.8] 1-1/2" [38.1]
Coax Volume
Volume (US Gallons) [liters] 1.62 [6.13] 1.81 [6.85] 2.40 [9.08]
Condensate Connection Size
FPT (in) [mm] 3/4" [19.1]
Air Coil Data
Air Coil Dimensions H x W (in) [cm] 20 x 54 [50.8 x 137.2] 20 x 64 [50.8 x 162.6]
Air Coil Total Face Area (ft
2
) [m
2
]
7.5 [0.70] 8.9 [0.83]
Miscellaneous Data
Filter Standard - 1" [25.4mm] Throwaway
(qty) (in) [cm]
(QTY.3) 16 x 20 [40.6 x 50.8]
(QTY.1) 20 x 20 [50.8 x 50.8]
Weight - Operating (lbs) [kg] 586 [265.8] 644 [292.1] 698 [316.6]
Weight - Packaged (lbs) [kg] 626 [283.9] 684 [310.3] 738 [334.8]
All units have grommet compressor mountings, and 1/2" & 1-3/4" electrical knockouts.
TCH Series 072 096 120
Water Coil Dimensions (in) [cm]
20 x 54 [50.8 x 137.2] 20 x 60 [50.8 x 152.4]
Internal Water Coil Volume (Gal) [L]
5.6 [21.6] 6.2 [23.5] 6.8 [25.7]
Weight - Operating (lbs.) [Kg]
838 [380] 921 [418] 998 [453]
Weight - Packaged (lbs.) [Kg]
900 [408] 978 [444] 1058 [480]
