CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Compact Belt Drive (TCH/V) Series
Rev.: July 25, 2017
30
ClimateMaster Water-Source Heat Pumps
TCV Field Conversion of Water Connections
Overview -
All models the water connection can be fi eld
converted to opposite side. Connections can be both
left, right, or 1 each side.
Preparation - Field conversion must be completed on
the ground. If the unit is already hung it should be taken
down for the fi eld conversion. Place in a well-lighted
area. Conversion should only be attempted by a qualifi ed
service technician.
Side to Back Discharge Conversion
Step 1: Remove panels needed for access to water connections.
Step 2: Remove screws from side panels. Loosen (4x) screws in slots
but do not remove.
Step 3: Both water in and out have a union centered in the middle of
the unit. Undo both unions, rotate the water legs for opposite confi gu-
ration retighten unions, reattach connection fl anges to wrappers. Use
slots to adjust and retighten screws in slots.
Step 4: Replace panels.
Step 5: Check wiring is per wire diagram.
Step 6: Replace panels
WARNING!
WARNING! To avoid possible injury or death due to
electrical shock, open the power supply disconnect switch
and secure it in an open position during installation or
conversion.
