ClimateMaster Water-Source Heat Pumps
Blower Performance Data – TCV300 Standard Unit
SCFM ESP 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50
7500
BHP 2.69 2.84 2.96 3.11 3.27 3.45 3.60 3.78 3.96 4.08 4.23 4.38 4.53 4.69 4.86 5.03
Sheave/Mtr BBBBAAAAAAAAACCC
RPM 890 925 955 990 1020 1050 1075 1105 1135 1155 1180 1205 1230 1255 1275 1295
Turns Open 4.5 3.5 2.5 2 5.5 5 4.5 3.5 3 3 2 1.5 1 3.5 3 2.5
7800
BHP 2.87 3.04 3.18 3.36 3.54 3.72 3.87 4.05 4.20 4.35 4.50 4.65 4.80 4.97 5.14 5.30
Sheave/Mtr B B B AAAAAAAAACCCC
RPM 910 945 975 1010 1040 1070 1095 1125 1150 1175 1200 1225 1250 1270 1290 1310
Turns Open 4 3 2 5.5 5 4.5 4 3 2.5 2.5 1.5 1 4 3 2.5 2.5
8100
BHP 3.10 3.26 3.42 3.60 3.78 3.96 4.14 4.34 4.52 4.70 4.88 5.06 5.21 5.35 5.53 5.68
Sheave/Mtr B B B AAAAAAAACCCCC
RPM 935 965 995 1025 1055 1085 1115 1145 1170 1195 1220 1245 1265 1285 1310 1330
Turns Open 3.5 2.5 1.5 5.5 5 4 3.5 3 2.5 2 1.5 4 3.5 3 2.5 2
8400
BHP 3.36 3.52 3.74 3.92 4.14 4.36 4.57 4.75 4.93 5.11 5.29 5.47 5.62 5.80 5.94 6.12
Sheave/Mtr B B AAAAAAAAACCCCC
RPM 955 985 1020 1045 1075 1105 1135 1160 1185 1210 1235 1260 1280 1305 1325 1350
Turns Open 3 2 5.5 5 4.5 3.5 3 2.5 2 1.5 1 3.5 3 2.5 2 1.5
8700
BHP 3.60 3.79 4.00 4.22 4.43 4.65 4.83 5.01 5.19 5.37 5.55 5.76 5.97 6.14 6.35 6.56
Sheave/Mtr B AAAAAAAAACCCCCC
RPM 975 1005 1035 1065 1095 1125 1150 1175 1200 1225 1250 1275 1300 1320 1345 1370
Turns Open 2.5 6 5 4.5 43321.513.532.521.51
9000
BHP 3.90 4.12 4.30 4.51 4.73 4.91 5.09 5.30 5.48 5.66 5.89 6.08 6.32 6.56 6.76
Sheave/Mtr AAAAAAAAACCCCCC
RPM 1000 1030 1055 1085 1115 1140 1165 1195 1220 1245 1270 1290 1315 1340 1360
Turns Open 6 5.5 4.5 4 3.5 3 2.5 1.5 1 3.5 3 2.5 2 1.5 1.5
9300
BHP 4.34 4.56 4.74 4.96 5.14 5.35 5.53 5.71 5.89 6.08 6.29 6.50 6.67 6.88 7.05
Sheave/Mtr AAAAAAAAACCCCCC
RPM 1020 1050 1075 1105 1130 1160 1185 1210 1235 1260 1285 1310 1330 1355 1375
Turns Open 5.5 5 4.5 3.5 3 2.5 2 1.5 1 3 3 2.5 2 1.5 1
9600
BHP 4.64 4.85 5.03 5.25 5.46 5.67 5.88 6.13 6.34 6.52 6.66 6.84 7.02 7.16
Sheave/Mtr AAAAAAAACCCCCC
RPM 1040 1070 1095 1125 1150 1175 1200 1230 1255 1280 1300 1325 1350 1370
Turns Open 5 4.5 4 3.5 3 2 1.5 1 3.5 3 2.5 2 1.5 1
9900
BHP 4.93 5.15 5.33 5.53 5.78 5.99 6.20 6.41 6.62 6.83 7.04 7.21 7.42
Sheave/Mtr AAAAAAACCCCCC
RPM 1060 1090 1115 1140 1170 1195 1220 1245 1270 1295 1320 1340 1365
Turns Open 4.5 4 3.5 3 2.5 1.5 1.5 3.5 3 2.5 2 2 1.5
10200
BHP 5.36 5.57 5.77 5.95 6.17 6.35 6.53 6.74 6.94 7.18 7.42 7.61
Sheave/Mtr AAAAAACCCCCE
RPM 1085 1110 1135 1160 1190 1215 1240 1265 1285 1310 1335 1355
Turns Open 4 3.5 3 2.5 2 1.5 4 3 3 2.5 2 1.5
10500
BHP 5.52 5.75 5.99 6.23 6.47 6.71 6.95 7.19 7.43 7.62 7.86 8.10
Sheave/Mtr AAAAAAC CCEEE
RPM 1100 1130 1155 1180 1205 1230 1255 1280 1305 1325 1350 1375
Turns Open 4 3 2.5 2 1.5 1 3.5 3 2.5 2 1.5 1
10800
BHP 6.00 6.24 6.48 6.72 6.96 7.20 7.39 7.63 7.87 8.11 8.30
Sheave/Mtr AAAAACC EEEE
RPM 1125 1150 1175 1200 1225 1250 1270 1295 1320 1345 1365
7000 3.5 3 5 1.5 1 3.5 3.5 2.5 2 1.5 1.5
All Data is Wet Coil
A = Standard Static/Standard Motor, B = Low Static/Standard Motor, C = High Static/Standard Motor, D = Standard Static/Large Motor, E = High Static/Large Motor
Unit factory shipped with standard static sheave and drive at 2.5 turns open. Other speed require fi eld selection.
For applications requiring higher static pressures, contact your local representative. Performance data does not include drive losses and is based on sea level conditions.
Do not operate in black regions. All airfl ow is rated at lowest Voltage if unit is dual Voltage rated, i.e. 208V for 208-230V units.
