THE SMART SOLUTION FOR ENERGY EFFICIENCY
Tranquility
®
Compact Belt Drive (TCH/V) Series
Rev.: July 25, 2017
63
climatemaster.com
Blower Performance Data – TCV192 Standard Unit
A = Standard Static/Standard Motor, B = Low Static/Standard Motor, C = High Static/Standard Motor, D = Standard Static/Large Motor, E = High Static/Large Motor
Unit factory shipped with standard static sheave and drive at 2.5 turns open. Other speed require fi eld selection.
For applications requiring higher static pressures, contact your local representative. Performance data does not include drive losses and is based on sea level conditions.
Do not operate in black regions. All airfl ow is rated at lowest Voltage if unit is dual Voltage rated, i.e. 208V for 208-230V units.
SCFM ESP 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50
4800
BHP 0.98 1.07 1.16 1.24 1.34 1.47 1.59 1.69 1.78 1.87 1.96 2.06 2.18 2.30 2.42
Sheave/Mtr BBBBAAAAAAACCCC
RPM 615 660 700 740 775 815 855 890 920 955 985 1015 1045 1075 1105
Turns Open 5.5 4.5 3 2 5.5 4 3.5 3 2.5 1.5 1 5.5 5 4.5 4
5000
BHP 0.99 1.07 1.18 1.27 1.37 1.49 1.60 1.73 1.82 1.92 2.00 2.10 2.22 2.32 2.44 2.56
Sheave/Mtr BBBBAAAAAAAACCCC
RPM 594 635 680 720 760 795 830 870 900 935 965 1000 1030 1055 1085 1115
Turns Open 6 5 4 2.5 5.5 5 3.5 3.5 3 2 1.5 1 5 4.5 4 3.5
5200
BHP 1.09 1.18 1.28 1.36 1.48 1.59 1.70 1.82 1.93 2.02 2.14 2.24 2.36 2.48 2.60 2.72
Sheave/Mtr BBBBAAAAAAACCCCC
RPM 620 660 700 735 775 810 845 880 915 945 980 1010 1040 1070 1100 1130
Turns Open 5.5 4.5 3.5 2 5.5 4.5 3.5 3 2.5 2 1 5.5 5 4.5 4 3.5
5400
BHP 1.19 1.29 1.39 1.48 1.59 1.70 1.80 1.92 2.03 2.16 2.26 2.38 2.50 2.62 2.74 2.87
Sheave/Mtr B B B AAAAAAAACCCCC
RPM 640 680 720 755 790 825 860 895 925 960 990 1020 1050 1080 1110 1140
Turns Open 5 4 2.5 6 5 4.5 3.5 3 2.5 1.5 1 5.5 5 4 3.5 3
5600
BHP 1.30 1.40 1.51 1.62 1.74 1.85 1.95 2.08 2.18 2.31 2.42 2.57 2.71 2.86 2.98 3.12
Sheave/Mtr B B B AAAAAAAC C C C C E
RPM 660 700 740 775 810 845 875 910 940 975 1005 1035 1065 1095 1120 1150
Turns Open 4.5 3.5 2 5.5 5 4 3 2.5 2 1.5 5.5 5 4.5 4 3.5 3
5800
BHP 1.41 1.52 1.63 1.73 1.84 1.95 2.06 2.18 2.32 2.44 2.57 2.72 2.86 3.00 3.15 3.27
Sheave/Mtr B B AAAAAAAACCCEEE
RPM 680 720 760 790 825 860 890 920 955 985 1015 1045 1075 1105 1135 1160
Turns Open 43654.53.532.51.515.554.5433
6000
BHP 1.56 1.67 1.78 1.89 2.00 2.12 2.24 2.36 2.48 2.60 2.74 2.89 3.01 3.15 3.30 3.42
Sheave/Mtr B B AAAAAAACCCEEEE
RPM 700 740 775 810 845 880 910 940 970 1000 1030 1060 1085 1115 1145 1170
Turns Open 3.5 2.5 5.5 5 4 3 2.5 2 1.5 6 5 4.5 4 3.5 3 2.5
6200
BHP 1.70 1.83 1.94 2.06 2.17 2.30 2.44 2.58 2.73 2.87 3.02 3.14 3.28 3.40 3.54 3.66
Sheave/Mtr B AAAAAAAACEEEEEE
RPM 720 760 795 830 865 895 925 955 985 1015 1045 1070 1100 1125 1155 1180
Turns Open 3 5.5 5 4.5 3.5 3 2.5 1.5 1 5.5 5 4.5 4 3.5 3 2.5
6400
BHP 1.88 2.02 2.16 2.28 2.42 2.54 2.66 2.78 2.90 3.04 3.16 3.31 3.43 3.58 3.72 3.86
Sheave/Mtr B AAAAAAACEEEEEEE
RPM 745 780 815 845 880 910 940 970 1000 1030 1055 1085 1110 1140 1165 1190
Turns Open 2.5 5 4.5 4 3.5 2.5 2 1.5 6 5 4.5 4 3.5 3 2.5 2
6600
BHP 2.06 2.18 2.32 2.46 2.58 2.70 2.82 2.94 3.07 3.19 3.34 3.46 3.60 3.74 3.88 4.02
Sheave/Mtr AAAAAAAAEEEEEEEE
RPM 765 795 830 865 895 925 955 985 1015 1040 1070 1095 1125 1150 1175 1200
Turns Open 5.5 5 4.5 3.5 3 2.5 1.5 1 5.5 5 4.5 4 3.5 3 2.5 2
6800
BHP 2.22 2.36 2.50 2.62 2.74 2.86 3.00 3.10 3.27 3.41 3.58 3.72 3.85 3.97 4.11 4.23
Sheave/Mtr AAAAAADDEEEEEEEE
RPM 780 815 850 880 910 940 970 1000 1030 1055 1085 1110 1135 1160 1190 1215
Turns Open 5.5 4.5 4 3.5 2.5 2 1.5 1 5 4.5 4 3.5 3 2.5 2 2
7000
BHP 2.40 2.54 2.66 2.80 2.92 3.04 3.14 3.27 3.39 3.54 3.66 3.78 3.96 4.12 4.28 4.44
Sheave/Mtr AAAAADDEEEEEEEEE
RPM 800 835 865 900 930 960 985 1015 1040 1070 1095 1120 1150 1175 1200 1225
7000 5 4 3.5 3 2 1.5 1 5.5 5 4.5 4 3.5 3 2.5 2 1.5
7200
BHP 2.58 2.70 2.85 2.99 3.14 3.28 3.42 3.54 3.66 3.81 3.93 4.06 4.22 4.38 4.54 4.70
Sheave/Mtr AAAADDEEEEEEEEEE
RPM 820 850 885 915 945 975 1005 1030 1055 1085 1110 1135 1160 1185 1210 1235
Turns Open 4.5 43321.55.554.543.532.52.521.5
7400
BHP 2.76 2.88 3.02 3.16 3.31 3.45 3.61 3.75 3.92 4.06 4.20 4.36 4.52 4.68 4.81 4.97
Sheave/Mtr A ADDDDEEEEEEEEEE
RPM 840 870 900 930 960 990 1020 1045 1075 1100 1125 1150 1175 1200 1220 1245
Turns Open 4 3.5 3 2.5 1.5 1 5.5 5 4.5 4 3.5 3 2.5 2 1.5 1.5
7600
BHP 2.94 3.07 3.22 3.36 3.50 3.63 3.82 3.98 4.14 4.34 4.50 4.66 4.78 4.94
Sheave/Mtr ADDDDEEEEEEEEE
RPM 860 890 920 950 980 1005 1035 1060 1085 1115 1140 1165 1185 1210
Turns Open 4 3 2.5 2 1 5.5 5 4.5 4 3.5 3 2.5 2 2
7800
BHP 3.22 3.34 3.49 3.63 3.78 3.96 4.12 4.28 4.44 4.63 4.76 4.92
Sheave/Mtr DDDDDEEEEEEE
RPM 880 905 935 965 995 1025 1050 1075 1100 1130 1150 1175
Turns Open 3.5 3 2 1.5 1 5.5 5 4.5 4 3.5 3 2.5
8000
BHP 3.41 3.58 3.75 3.92 4.06 4.26 4.42 4.58 4.74 4.90
Sheave/Mtr DDDDEEEEEE
RPM 895 925 955 985 1010 1040 1065 1090 1115 1140
Turns Open 3 2.5 1.5 1 5.5 5 4.5 4 3.5 3
All Data is Wet Coil
