Electrical - Line Voltage
Electrical - Line Voltage - All fi eld installed wiring, in-
cluding electrical ground, must comply with the National
Electrical Code as well as all applicable local codes. Refer
to the unit electrical data for fuse sizes. Consult wiring
diagram for fi eld connections that must be made by the
installing (or electrical) contractor. All fi nal electrical con-
nections must be made with a length of fl exible conduit to
minimize vibration and sound transmission to the building.
General Line Voltage Wiring - Be sure the available
power is the same voltage and phase shown on the unit
serial plate. Line and low voltage wiring must be done in
accordance with local codes or the National Electric Code,
whichever is applicable.
WARNING! To avoid possible injury or death due to electrical
shock, open the power supply disconnect switch and secure
it in an open position during installation.
CAUTION! Use only copper conductors for fi eld installed
electrical wiring. Unit terminals are not designed to accept
other types of conductors.
WARNING!
CAUTION!
Transformer - All 208/230 voltage units are factory wired
for 208 volt. If supply voltage is 230 volt, installer must
rewire transformer. See wire diagram for connections.
Table 4a: Tranquility
®
Compact (TCH/V) Series Electrical Data - (Standard 60Hz Units)
Model #
Voltage
Code
Voltage
Min/Max
Voltage
Blower
Option
Compressor
Fan
Motor
FLA
Total
FLA/
Rated
Current
Min
Circuit
Amp
SCCR ka
rms
symetrical
SCCR
Volts
Maximum
Max
Fuse/
HACR
QTY RLA LRA
TCH/V072
H 208/230/60/3 197/254 A, B, C 2 10.4 73.0 3.2 24.0 26.6 N/A N/A 35
H 208/230/60/3 197/254 D, E 2 10.4 73.0 6.0 26.8 29.4 N/A N/A 35
F 460/60/3 414/506 A, B, C 2 5.8 38.0 1.6 13.2 14.7 N/A N/A 20
F 460/60/3 414/506 D, E 2 5.8 38.0 2.9 14.5 16.0 N/A N/A 20
N 575/60/3 518/633 A, B, C 2 3.8 36.5 1.2 8.8 9.8 N/A N/A 15
N 575/60/3 518/633 D, E 2 3.8 36.5 2.4 10.0 11.0 N/A N/A 15
TCH/V096
H 208/230/60/3 197/254 A, B, C 2 13.7 83.1 6.0 33.4 36.8 N/A N/A 50
H 208/230/60/3 197/254 D, E 2 13.7 83.1 8.5 35.9 39.3 N/A N/A 50
F 460/60/3 414/506 A, B, C 2 6.2 41.0 2.9 15.3 16.9 N/A N/A 20
F 460/60/3 414/506 D, E 2 6.2 41.0 4.1 16.5 18.1 N/A N/A 20
N 575/60/3 518/633 A, B, C 2 4.8 33.0 2.4 12.0 13.2 N/A N/A 15
N 575/60/3 518/633 D, E 2 4.8 33.0 3.2 12.8 14.0 N/A N/A 15
TCH/V120
H 208/230/60/3 197/254 A, B, C 2 15.6 110.0 8.5 39.7 43.6 N/A N/A 50
H 208/230/60/3 197/254 D, E 2 15.6 110.0 13.8 45.0 48.9 N/A N/A 60
F 460/60/3 414/506 A, B, C 2 7.8 52.0 4.1 19.7 21.7 N/A N/A 25
F 460/60/3 414/506 D, E 2 7.8 52.0 6.5 22.1 24.1 N/A N/A 30
N 575/60/3 518/633 A, B, C 2 5.8 38.9 3.2 14.8 16.3 N/A N/A 20
N 575/60/3 518/633 D, E 2 5.8 38.9 5.2 16.8 18.3 N/A N/A 20
TCV160
H 208/230/60/3 197/254 A, B, C 2 23.2 164.0 8.5 54.9 60.7 5 600 80
H 208/230/60/3 197/254 D, E 2 23.2 164.0 13.8 60.2 66.0 5 600 80
F 460/60/3 414/506 A, B, C 2 11.2 75.0 4.1 26.5 29.3 N/A N/A 40
F 460/60/3 414/506 D, E 2 11.2 75.0 6.5 28.9 31.7 N/A N/A 40
N 575/60/3 518/633 A, B, C 2 7.9 54.0 3.2 19.0 21.0 N/A N/A 25
N 575/60/3 518/633 D, E 2 7.9 54.0 5.2 21.0 23.0 N/A N/A 30
TCV192
H 208/230/60/3 197/254 A, B, C 2 25.0 164.0 8.5 58.5 64.8 5 600 80
H 208/230/60/3 197/254 D, E 2 25.0 164.0 13.8 63.8 70.1 5 600 90
F 460/60/3 414/506 A, B, C 2 12.2 100.0 4.1 28.5 31.6 N/A N/A 40
F 460/60/3 414/506 D, E 2 12.2 100.0 6.5 30.9 34.0 N/A N/A 45
N 575/60/3 518/633 A, B, C 2 9.0 78.0 3.2 21.2 23.5 N/A N/A 30
N 575/60/3 518/633 D, E 2 9.0 78.0 5.2 23.2 25.5 N/A N/A 30
TCV240
H 208/230/60/3 197/254 A, B, C 2 30.1 225.0 13.8 74.0 81.5 5 600 110
H 208/230/60/3 197/254 D, E 2 30.1 225.0 21.0 81.2 88.7 5 600 110
F 460/60/3 414/506 A, B, C 2 16.7 114.0 6.5 39.9 44.1 N/A N/A 60
F 460/60/3 414/506 D, E 2 16.7 114.0 9.9 43.3 47.5 N/A N/A 60
N 575/60/3 518/633 A, B, C 2 12.2 80.0 5.2 29.6 32.7 N/A N/A 40
N 575/60/3 518/633 D, E 2 12.2 80.0 8.0 32.4 35.5 N/A N/A 45
TCV300
H 208/230/60/3 197/254 A, B, C 2 48.1 245.0 21.0 117.2 129.2 5 600 150
H 208/230/60/3 197/254 E 2 48.1 245.0 26.0 122.2 134.2 5 600 150
F 460/60/3 414/506 A, B, C 2 18.6 125.0 9.9 47.1 51.8 5 600 70
F 460/60/3 414/506 E 2 18.6 125.0 12.5 49.7 54.4 5 600 70
N 575/60/3 518/633 A, B, C 2 14.7 100.0 8.0 37.4 41.1 N/A N/A 50
N 575/60/3 518/633 E 2 14.7 100.0 10.2 39.6 43.3 N/A N/A 50
All fuses Class RK-5
