Tranquility
®
Compact Belt Drive (TCH/V) Series
Rev.: July 25, 2017
73
climatemaster.com
Start-Up Log Sheet
Installer: Complete unit and system checkout and follow unit start-up procedures in the IOM. Use this form to record
unit information, temperatures and pressures during start-up. Keep this form for future reference.
Job Name: Street Address:
Model Number: Serial Number:
Unit Location in Building:
Date: Sales Order No:
In order to minimize troubleshooting and costly system failures, complete the following checks and data entries before
the system is put into full operation.
External Static:
Sheave Setting: Turns Open
Temperatures: F or C Antifreeze: %
Pressures: PSIG or kPa Type:
Cooling Mode Heating Mode
Return-Air Temperature DB WB DB
Supply-Air Temperature DB WB DB
Temperature Differential
Entering Fluid Temperature
Leaving Fluid Temperature
Temperature Differential
Water Coil Heat Exchanger
(Water Pressure IN)
Water Coil Heat Exchanger
(Water Pressure OUT)
Pressure Differential
Flow Rate GPM (l/s)
Compressor
Amps
Volts
Discharge Line Temperature
Motor
Amps
Volts
Allow unit to run 15 minutes in each mode before taking data.
Do not connect gauge lines
To Next Page
