CLIMATEMASTER WATER-SOURCE HEAT PUMPS
Tranquility
®
Compact Belt Drive (TCH/V) Series
Rev.: July 25, 2017
64
ClimateMaster Water-Source Heat Pumps
Blower Performance Data – TCV240 Standard Unit
SCFM ESP 0.00 0.10 0.20 0.30 0.40 0.50 0.60 0.70 0.80 0.90 1.00 1.10 1.20 1.30 1.40 1.50
6000
BHP 1.78 1.89 2.00 2.12 2.24 2.36 2.48 2.60 2.74 2.89 3.01 3.15 3.30
Sheave/Mtr B B B AAAAAAAACC
RPM 775 810 845 880 910 940 970 1000 1030 1060 1085 1115 1145
Turns Open 5.5 4.5 4 6 5 4.5 3.5 3 2.5 1.5 1 3.5 3
6200
BHP 1.82 1.93 2.04 2.15 2.30 2.44 2.58 2.73 2.87 2.99 3.14 3.26 3.40 3.52
Sheave/Mtr BBBBAAAAAAACCC
RPM 755 790 825 860 895 925 955 985 1015 1040 1070 1095 1125 1150
Turns Open 6 5 4.5 3.5 5.5 5 4 3.5 2.5 2 1.5 4 3.5 3
6400
BHP 2.00 2.14 2.26 2.40 2.52 2.64 2.76 2.88 3.02 3.14 3.28 3.40 3.56 3.70
Sheave/Mtr BBBBAAAAAAACCC
RPM 775 810 840 875 905 935 965 995 1025 1050 1080 1105 1135 1160
Turns Open 5.5 4.5 4 3 5.5 4.5 4 3 2.5 21432.5
6600
BHP 2.02 2.16 2.30 2.42 2.56 2.68 2.80 2.92 3.05 3.17 3.29 3.43 3.55 3.71 3.85
Sheave/Mtr BBBBAAAAAAAACCC
RPM 755 790 825 855 890 920 950 980 1010 1035 1060 1090 1115 1145 1170
Turns Open 6 5.5 4.5 3.5 6 5 4 3.5 3 2 1.5 1 3.5 3 2.5
6800
BHP 2.18 2.32 2.46 2.58 2.70 2.84 2.94 3.06 3.21 3.35 3.52 3.66 3.82 3.94 4.06
Sheave/Mtr BBBBAAAAAAACCCC
RPM 770 805 840 870 900 935 960 990 1020 1045 1075 1100 1130 1155 1180
Turns Open 5.5 5 4 3 5.5 4.5 4 3 2.5 2 1 4 3.5 2.5 2
7000
BHP 2.22 2.34 2.48 2.62 2.74 2.86 2.98 3.10 3.22 3.34 3.49 3.61 3.73 3.90 4.06 4.22
Sheave/Mtr BBBBAAAAAAAACCCC
RPM 755 785 820 855 885 915 945 975 1005 1030 1060 1085 1110 1140 1165 1190
Turns Open 6 5.5 4.5 3.5 6 5 4.5 3.5 3 2.5 1.5 1 3.5 3 2.5 2
7200
BHP 2.38 2.52 2.64 2.78 2.92 3.06 3.21 3.35 3.47 3.62 3.74 3.88 4.00 4.16 4.32 4.48
Sheave/Mtr BBBBAAAAAAACCCCC
RPM 770 805 835 870 900 930 960 990 1015 1045 1070 1100 1125 1150 1175 1200
Turns Open 5.5 5 4 3.5 5.5 4.5 4 3 2.5 2 1.5 4 3.5 3 2 1.5
7400
BHP 2.56 2.68 2.82 2.95 3.09 3.24 3.38 3.53 3.67 3.84 3.98 4.12 4.26 4.42 4.58 4.74
Sheave/Mtr B B B AAAAAAAACCCCC
RPM 790 820 855 885 915 945 975 1005 1030 1060 1085 1110 1135 1160 1185 1210
Turns Open 5 4.5 3.5 6 5 4.5 3.5 3 2.5 1.5 1 3.5 3 2.5 2 1.5
7600
BHP 2.74 2.86 2.98 3.12 3.26 3.41 3.55 3.70 3.89 4.05 4.21 4.40 4.53 4.69 4.85 5.01
Sheave/Mtr B B B AAAAAAAC C C C C E
RPM 810 840 870 900 930 960 990 1015 1045 1070 1095 1125 1145 1170 1195 1220
Turns Open 4.5 4 3.5 5.5 4.5 4 3 2.5 2 1.5 4 3.5 3 2.5 2 1.5
Table Continued on Next Page
A = Standard Static/Standard Motor, B = Low Static/Standard Motor, C = High Static/Standard Motor, D = Standard Static/Large Motor, E = High Static/Large Motor
Unit factory shipped with standard static sheave and drive at 2.5 turns open. Other speed require fi eld selection.
For applications requiring higher static pressures, contact your local representative. Performance data does not include drive losses and is based on sea level conditions.
Do not operate in black regions. All airfl ow is rated at lowest Voltage if unit is dual Voltage rated, i.e. 208V for 208-230V units.
All Data is Wet Coil
