Table 2c. Torque Specifi cation: Models J-RR, RT, RRT
Fastener Screw Size Tool Required
*Recommended Seating Torque
ft-lbf N-m
Motor Housing / Gear Housing /
Back Frame Screws
5/16"-18 Socket Head Cap Screw 1/4" Hex Driver 14.2 - 15.0 19.2 - 20.3
Lift-Wheel Nut 1-1/8"-12 Hex Nut 1-11/16" - 6 or 12 Point Socket 85.0 - 90.0 115.2 - 122.0
Brake Attaching Screw 5/16-18 Slotted Fillister Head Screw Slotted Blade Screw Driver 4.2 - 5.0 5.6 - 6.8
Brake Armature Mounting Screws M6 Socket Head Cap Screw 5mm Hex Driver 7.1 - 7.9 9.6 - 10.7
Stator Mounting Screws 1/4"-20 Hex Cap Screw 7/16" - 6 or 12 Point Socket 4.2 - 5.0 5.6 - 6.8
Suspension Adapter Screws 1/2"-20 12-Point Cap Screw 1/2" - 12 Point Socket 70.0 - 80.0 94.9 - 108.5
Lower Hook Block Screws
-Double Reeved
5/16"-18 Socket Head Cap Screw 1/4" Hex Driver 10.0 - 11.3 13.6 - 15.3
Loose End Screw 5/16"-18 Hex Cap Screw 1/2" - 6 or 12 Point Socket 8.0 - 10.0 10.8 - 13.6
Chain Stop Screw 1/4"-20 Socket Head Cap Screw 3/16" Hex Driver 5.0 - 5.8 6.8 - 7.9
Table 2d. Torque Specifi cation: Model RRS
Fastener Screw Size Tool Required
*Recommended Seating Torque
ft-lbf N-m
Main Frame/Intermediate Frame/Back Frame
Screws
5/16"-18 Socket Head Cap Screw 1/4" Hex Driver 14.2 - 15.0 19.2 - 20.3
3rd Pinion Nut 1-1/8"-12 Hex Nut 1-11/16" - 6 or 12 Point Socket 85.0 - 90.0 115.2 - 122.0
Chain Chute Pin Set Screw Torque 1/2-13 Hex Recess Set Screw 1/4" Hex Driver 11.7 - 13.3 15.8 - 18.1
Brake Attaching Screw 5/16-18 Slotted Fillister Head Screw Slotted Blade Screw Driver 4.2 - 5.0 5.6 - 6.8
Brake Armature Mounting Screws M6 Socket Head Cap Screw 5mm Hex Driver 7.1 - 7.9 9.6 - 10.7
Stator Mounting Screws 1/4"-20 Hex Cap Screw 7/16" - 6 or 12 Point Socket 4.2 - 5.0 5.6 - 6.8
Suspension Retainer Screw 1/4"-20 Socket Head Cap Screw 3/16" Hex Driver 4.2 - 5.0 5.6 - 6.8
Chain Container Bracket Mounting Screws 9/16"-18 Hex Cap Screw 7/16" Hex Driver 20.0 - 50.0 27.1 - 67.8
Chain Stop Screws 5/16"-18 Socket Head Cap Screw 1/4" Hex Driver 10.0 - 13.0 13.6 - 17.6
*All Torque values are for clean,dry fasteners. DO NOT apply oil or any other lubricant to the fastener threads
