94
00001996 (REV AC) 627NH October 2014
LUBRICANTS
Part Number for Packaged Lubricants
Used in the Lodestar Electric Chain Hoists
(Refer to page 21 for Lubrication Instructions)
Lubricant
Usage
Type of
Lubricant
Part Numbers and
Packaged Quantity of Lubricants
Hoist Gears Grease (Special)
Models A to H uses 28605
Model J to RRT excluding RRS uses 28617
Model RRS uses 1 each of both 28605 and 28617
Load Chain Oil
28608 for 1 Pint Can
28619 for 1 Gal Can
Limit Switch Shaft Threads *Oil
“3 in 1” or Light Machine
Oil-obtain locally
Lower Hook Thrust Bearing *Oil Heavy Machine Oil obtain locally
* These oils are not furnished by CM in Packaged Quantities. When
ordering lubricants, specify the type of lubricant, part number and
packages quantity required.
Touch-up Paints for Lodestar Electric Chain Hoists:
Hoist Order *(1) case (12-12 oz. Aerosol Cans) of Black
Touch-up paints Part Number 84189.
Hoist Order *(1) case (12-12 oz. Aerosol Cans) of Orange
Touch-Up paint Part Number 84190.
*Touch-up paints are only available in case quantities.
NOTE: When painting hoists, also order warning labels,
identifi cation labels, etc. that may be coated during painting.
RECOMMENDED SPARE PARTS
To insure continued service of the Lodestar Hoist, the
following is a list of parts that are recommended to be kept
on hand at all times to replace parts that have worn of failed.
Part Description Models A-H Models J-RRT Model RRS Qty Required for Each Hoist
Limit Switch Kit 31631 31636 (excludes RRS) 31636 1
Solid State Reverse Switch
(Single Phase Units Only)
27257 35499 n/a 1
Start Capacitor
(Single Phase Units Only)
27716 35279 n/a 1
Run Capacitor
(Single Phase Units Only)
- 35278 n/a
Transformer
SEE CONTACTOR PLATE
SECTION
SEE CONTACTOR PLATE
SECTION
SEE CONTACTOR PLATE
SECTION
0 or 1
Control Station Hardware Kit
w/ Gasket
SEE CONTROLS SECTION SEE CONTROLS SECTION SEE CONTROLS SECTION 1
Control Station Button Insert Kit SEE CONTROLS SECTION SEE CONTROLS SECTION SEE CONTROLS SECTION 1
Contactor
SEE CONTACTOR PLATE
SECTION
SEE CONTACTOR PLATE
SECTION
SEE CONTACTOR PLATE
SECTION
1
Fuse - 500mA 00000393 00000393 00000393
Speed Selector Relay
(2-Speed Units Only)
SEE CONTACTOR PLATE
SECTION
SEE CONTACTOR PLATE
SECTION
SEE CONTACTOR PLATE
SECTION
1
CM Terminal Pin-Extraction Tool
(Dual Voltage Only)
27163 27163 27163 1
Suspension Bolts 987554 36846 10001047/82638 2(1 EA RRS)
