65
00001996 (REV AC) 627NH October 2014
Item No. Decription Part Number Qty.
1 GEARBOX ASSEMBLY 10001000 1
1.1 MAIN FRAME SUB ASSEMBLY-ORANGE 10001001C 1
1.2 CHAIN GUIDE 10001004 1
1.3 LIFTWHEEL-5PKT-10MM X 30MM 10001074 1
1.4 RADIAL BALL BEARING 10001017 1
1.5 GEAR-33T 10001006 1
1.6 RETAINING RING-EXTERNAL 10001108 2
1.7 PINION SUB-ASSY-12T 10001007 1
1.8 RETAINING RING-EXTERNAL 10001107 1
1.9 SPRING PIN 983784 4
1.1 GASKET-GEAR HOUSING-V2 00000192 2
1.11 INT. FRAME-SUB-ASSY-ORANGE 10001009C 1
1.12 SCREW 982682 5
1.13 GEAR - 42 TEETH 00000162 1
1.14 WASHER-LOCK-EXT TOOTH 986276 1
1.15 NUT 35773 1
1.16 SHAFT SUB-ASSY 10T/92T 10001011 1
1.17 DOWEL, BACK FRAME 35768 2
1.18 DRIVE SHAFT-10T 10001012 1
1.19 V2 BACK FRAME S/A-ORANGE 00000510C 1
1.20 SCREW 80409 4
1.21 LOCK WASHER 940830 4
1.22 CHAIN CHUTE-MACHINED-BLACK 10001014B 1
1.23 DOWEL PIN 10001038 2
1.24 SET SCREW 10001045 2
1.25 CYLINDRICAL ROLLER BEARING 10001016 1
RRS GEARBOX
