CM Lodestar A - Page 52

52
00001996 (REV AC) 627NH October 2014
Item No. Description
MODELS
A & A-2
MODELS
AA & AA-2
MODELS
B & B-2
MODELS
C & C-2
MODELS
E & E-2
MODELS
F & F-2
MODELS
H & H-2
QTY.
25 LIMIT SWITCH BRACKET S/A - 1ø 00000532
1
LIMIT SWITCH BRACKET S/A - 3ø 00000531
26 LIMIT SWITCH BRACKET SCREWS 982708 2
27 LIMIT SWITCH SPRING GUIDE 52737
1
LIMIT SWITCH GUIDE PLATE 28714
28 LIMIT SWITCH GUIDE MOUNTING SCREW 983614 2
29 EMPTY ––
30 MOTOR COVER 27058
1
MOTOR COVER - CLEAN ROOM 27034
31 BACK FRAME COVER 28009C
1
BACK FRAME COVER - CLEAN ROOM 28009W
32 EMPTY ––
33 MOTOR COVER SCREW 987397 2
34 WASHER 982251 5
35 SCREW RETAINER 00001747 3
36 BACK FRAME COVER SCREW 87325 3
37 TRANSFORMER 24V SECONDARY 00000586T
1TRANSFORMER 48V SECONDARY 00000587T
TRANSFORMER 120V SECONDARY 00000588T
38 LOCK WASHER 982226 2
39 TRANSFORMER MOUNTING SCREW 982688 2
40 UPPER SUSPENSION ASSEMBLY SEE SUSPENSION SECTION 1
40. 1 SUSPENSION BOLT 987554 2
41
HARNESS-110/115V-1-50/60, 110/115V CON-
TROL
00001516
1
HARNESS-110/115V-1-50/60, 24/48V CONTROL 00001517
HARNESS-220/230V-1-50/60 00001522
HARNESS-220/230/380/415/460V-3-50/60 00001518
HARNESS-550/575V-3-50/60 00000807
HARNESS-220/230V-1-50/60, 2 SPEED 00000764
HARNESS-380/415/460V-1-50/60, 2 SPEED 00001519
HARNESS-550/575V-1-50/60, 2 SPEED 00000769
HARNESS-230-3-60, VFD 00001558
HARNESS-460-3-60, VFD 00001559
42 HARNESS-V1 (3Ø ONLY) 00000749 1
43 WARNING LABEL 00000779 1
44 SERIES LABEL 00000780 1
45 CAPACITY LABEL 00000581 00000772 00000773 00000778 1
MODELS A, A-2, AA, AA-2, B, B-2, C, C-2, E, E-2, F, F-2, H & H-2 (CONT.)
