56
00001996 (REV AC) 627NH October 2014
Item No. Description
MODELS
J & J-2
MODELS
JJ & JJ-2
MODEL L
MODEL
L-2
MODELS
LL & LL-2
MODELS
R & R-2
MODELS
RR & RR-2
MODELS
RT & RT-2
MODELS
RRT &
RRT-2
QTY.
29
TERMINAL STRIP S/A (115V-1Ø) 00001739
1
TERMINAL STRIP S/A (230V-1Ø) 00001738
TERMINAL STRIP S/A (230/460V-3Ø) 00001734
TERMINAL STRIP S/A (575V-1Ø) 00001735
TERMINAL STRIP S/A (230V-2 SPEED) 00001736
TERMINAL STRIP S/A (460/575V-2
SPEED)
00001746
30 MOTOR COVER 36025C 1
31 BACK FRAME COVER ASSEMBLY 00000578C 1
31.1 BACK FRAME COVER 36008C 1
31.2 COUNTER WEIGHT 00000565 1
31.3 COUNTER WEIGHT SCREW 00000576 4
31.4 TETHER 00000575 1
31.5 SCREW 00000577 1
31.6 WASHER 00000554 1
32 BACK FRAME COVER PINS 983784 4
33 MOTOR COVER SCREW 987553 2
34 WASHER 982251 6
35 SCREW RETAINER 00001747 6
36 BACK FRAME COVER SCREW 968752 4
37-39 EMPTY – –
40 UPPER SUSPENSION ASSEMBLY SEE SUSPENSION SECTION 1
40.1 SUSPENSION BOLT 36849 2
41
HARNESS-110/115V-1-50/60, 110/115V
CONTROL
00001530
1
HARNESS-110/115V-1-50/60, 24/48V
CONTROL
00001523
HARNESS-220/230V-1-50/60 00001523
HARNESS-
220/230/380/415/460V-3-50/60
00001531
HARNESS-550/575V-3-50/60 00001534
HARNESS-220/230V-1-50/60, 2 SPEED 00001532
HARNESS-380/415/460V-1-50/60, 2
SPEED
00001533
HARNESS-550/575V-1-50/60, 2 SPEED 00001533
HARNESS-230-3-60, VFD 000001556
HARNESS-460-3-60, VFD 00001556
42 EMPTY – –
43 WARNING LABEL 00000779 1
44 SERIES LABEL 00000781 1
45 CAPACITY LABEL 00000774 00000775 00000776 00000777 1
46
POWER CORD-110/115V-1-50/60 29042
1POWER CORD-220/230V-1-50/60 29042
POWER CORD-3Ø (1 & 2 SPEED) 23606515
47 CONTROL STATION AND CORD SEE CONTROL STATION SECTION 1
48 WARNING TAG 68209 1
MODELS J, J-2, JJ, JJ-2, L, L-2, LL, LL-2, R, R-2, RR, RR-2, RT, RT-2,
RRT, & RRT-2 (CONT.)
