59
00001996 (REV AC) 627NH October 2014
MODEL RRS
Item No. Decription Part Number Qty.
1 GEARBOX ASSEMBLY-ORANGE 10001000C 1
2 CLUTCH ASSEMBLY-V2-2 HP 00000243 1
3
MOTOR - 230/460V-WITH PLUG 10001023
1
MOTOR 2HP- 575V 10001024
4 EMPTY ––
5 EMPTY ––
6 GASKET-MOTOR COVER 10001019 1
7 EMPTY ––
8 LOCK WASHER 982226 4
9 MOTOR MOUNTING SCREW 87334 4
10 CONTACTOR PLATE ASSEMBLY SEE CONTACTOR PLATE SECTION 1
11 CONTACTOR PLATE MOUNTING SCREWS 983656 3
12 EMPTY ––
13 EMPTY ––
14 BRAKE ASSEMBLY SEE BRAKE SECTION 1
14a BRAKE HUB SPACER 00001433 1
14b BRAKE HUB 00001431 1
14c BRAKE HUB SNAP RING 10409711 1
15 LOCK WASHER 945851 2
16 BRAKE MOUNTING SCREW 982709 2
17 EMPTY ––
18 BACK FRAME COVER GASKET 00000236 1
19 EMPTY ––
20
LIMIT SWITCH SHAFT S/A - 44 TPI 00000524
1LIMIT SWITCH SHAFT S/A - 56 TPI 00000526
LIMIT SWITCH SHAFT S/A - 64 TPI 00000528
21 LIMIT SWITCH SHAFT SPRING 35703 1
22 EMPTY ––
23 LIMIT SWITCH BEARING 35751 2
24 LIMIT SWITCH BEARING SCREWS 983656 2
25 LIMIT SWITCH BRACKET S/A 36827 1
26 LIMIT SWITCH BRACKET SCREWS 983656 2
27 LIMIT SWITCH GUIDE PLATE 28714 1
28 LIMIT SWITCH GUIDE PLATE MOUNTING SCREWS 983614 2
29
TERMINAL STRIP S/A (230/460V-3ø) 00001734
1
TERMINAL STRIP S/A (575V-3ø) 00001735
30 MOTOR COVER 36025C 1
31 BACK FRAME COVER 36008C 1
32 BACK FRAME COVER PINS 983784 4
33 MOTOR COVER SCREW 987553 2
34 WASHER 982251 6
35 SCREW RETAINER 00001747 6
36 BACK FRAME COVER SCREW 968752 4
37 HOLE PLUG 00000574 4
38 SUSPENSION RETAINER SCREW 10001047 1
39 SUSPENSION RETAINER NUT 82638 1
40 UPPER SUSPENSION ASSEMBLY SEE SUSPENSION SECTION 1
41
WIRING HARNESS (230/460V-3ø) 00001531
1
WIRING HARNESS (575V-3ø) 00001534
42 LINE CONNECTOR (NOT SHOWN) 982158 1
43 EMPTY ––
44 SERIES LABEL 00000781 1
45 CAPACITY LABEL 00000776 1
46
POWER CORD 23606515
1
KIT, LESS POWER CORD 28039
47 CONT STATION AND CORD SEE LOWER HOOK BLOCK SECTION 1
48 EMPTY ––
49 GROUND SCREW 987827 2
50 LOCK WASHER 982226 2
51 CHAIN CONTAINER BRACKET 10001041 1
52 WASHER 10001043 2
53 SCREW 982433 2
54 LOWER HOOK ASSEMBLY 10001052 1
55 CHAIN BLOCK KIT 10001029 1
56 CHAIN STARTER LINK (NOT SHOWN) 85960LEL 1
57 LOAD CHAIN, ZINC PLATED 85960EN REQ'D LIFT +2FT
