CM Lodestar A - Page 61

61
00001996 (REV AC) 627NH October 2014
Item No. Description
DC TYPE BRAKE
Qty.
Model A Model AA
MODELS
B/ E
MODELS
B/ E
MODELS
F/ H
1
GEARBOX SUB-ASSEMBLY 00000830C 00000831C 00000832C 00000833C 00000834C
1
CLEAN ROOM GEAR BOX SUB-ASSEMBLY 00000835W 00000836W 00000837W 00000838W 00000839W
1.1
MOTOR HOUSING
SUB-ASSY
00000504C
1
CLEAN ROOM MOTOR HOUSING 1SUB-ASSY 00000504W
1.2
CHAIN GUIDE 00000232
2
CLEAN ROOM
CHAIN GUIDE
00000811
1.3
LIFTWHEEL 00000500
1
CLEAN ROOM LIFTWHEEL 00000818
1.4 DOWEL PIN 82354 4
1.5
GASKET-MOTOR
HOUSING WIREWAY
00000189 1
1.6 GASKET MOTOR HOUSING 00000190 1
1.7 GASKET MOTOR HOUSING 00000191 1
1.8 EMPTY ––
1.9 SUSPENSION NUT 927755 2
1.10 LOOSE END NUT 82638 1
1.11
GEAR HOUSING SUB-ASSY 00000503C 00000503C 00000502C 00000503C 00000502C
1
CLEAN ROOM GEAR
HOUSING SUB-ASSY
00000503W 00000503W 00000502W 00000503W 00000502W
1.12 LOCK WASHER 940802 7
1.13 GEAR HOUSING SCREW 28830 4
1.14 LIFTWHEEL GEAR
00000160
(45TEETH)
00000159
(36TEETH)
00000161
(59TEETH)
00000160
(45TEETH)
00000161
(59TEETH)
1
1.15 LOCK WASHER 00000199 1
1.16 LIFTWHEEL NUT 00000198 1
1.17 EMPTY ––
1.18 GEAR HOUSING GASKET 00000188 1
1.19 INTERMEDIATE SHAFT SUB-ASSY
00000156
(88TEETH/ 12TEETH)
00000157
(88TEETH/ 18TEETH)
00000155
(88TEETH/ 8TEETH)
00000156
(88TEETH/ 12TEETH)
00000155
(88TEETH/ 8TEETH)
1
1.20
BACK FRAME SUB-ASSY 00000505C*
1
CLEAN ROOM BACK FRAME SUB-ASSY 00000505W*
1.21 DRIVE SHAFT 00000819 (10 TEETH) 1
1.22 BRAKE HUB SEE BRAKE SECTION 1
1.23 RETAINING RING SEE BRAKE SECTION 1
1.24 SPACER SEE BRAKE SECTION 1
1.25 BACKFRAME SCREW 982699 3
MODELS A, A-2, AA, AA-2, B, B-2, C, C-2, E, E-2, F, F-2, H & H-2 (CONT.)
