COBHAM EXPLORER 540 - Page 125

Appendix A: Technical specifications
98-148232-E Interfaces specifications 117
USB (Host) interface (X6)
The USB interface is used for connecting the optional EXPLORER 540 LTE Modem for cellular
operation.
Connector pin-out
Specifications
Pin Function
1+5V
2Dm
3Dp
4ID
5GND
USB Micro B
Item Specification
Version USB v2.0 Host
Connector type
Type Micro B
