Chapter 4: Configuration with web interface
98-148232-E Advanced settings 90
3. Select whether the Terminal ready output should be active high or low. This output
signals when the EXPLORER 540 is registered on the BGAN network and is ready to
communicate with connected equipment.
4. If you want to use GPIO pin 3, select the direction and polarity.
Pin 3 does not have a predefined function, but can be used for remote control/status of
connected M2M equipment using AT command _ITGPIO. See Control or status with
GPIO pin 3 on page 46.
5. Click Save.
Help desk
Under Help desk you can enter the contact information you want for your EXPLORER 540. The
Help desk contact information is empty by default. You must provide the contact information,
e.g. the phone number for your Airtime Provider. Do as follows:
1. In the Advanced page, select Help desk.
2. Type in the contact information you want.
3. select Save.
The Help desk information is now available from
(Control panel) > Support > About.
Reset button
You can change the function of the Reset button. See Reset button on page 101. Do as
follows:
1. From the Advanced page, select Reset Button.
2. Select the behavior you want for the Reset button.
• Enabled: Short push: The EXPLORER 540 restarts (power cycle) and begins the
installation process again., Long push: Reset to factory default.
• Long press disabled: The Reset button will not be able to reset to factory default, but
the short push function (power cycle) will still work.
• Disabled: The Reset button will not have any function.
3. Click Save.
“Terminal ready” only signals that the terminal is awake, registered on the BGAN
network and ready to communicate with connected equipment. It does not
show whether or not a data connection is established. See Power-saving on
page 40 and Automatic Context Activation (ACA) on page 36.
