SAILOR 100 GX specifications
A-2 Appendix A: Technical specifications 98-141779-G
A.1 SAILOR 100 GX specifications
SYSTEM SPECIFICATIONS
Frequency band Ka-band (Inmarsat GX)
Reflector size 103 cm / 40.6”
Type approvals Inmarsat
Certification Compliant with CE (Maritime), ETSI, FCC
System power supply range 100-240 VAC, 50-60 Hz
Total system power consumption 175W typical, 370W peak
Vibration, operational Sine: EN60945 (8.7.2), DNV 2.4A, MIL-STD-167-1 (5.1.3.3.5).
Vibration, survival Sine: EN60945 (8.7.2) dwell, MIL-STD-167-1 (5.1.3.3.5) dwell. EN60721-3-6 class 6M3
mod. by EN60721-4-6
Shock EN60721-3-6 class 6M3 mod. by EN60721-4-6.
Temperature (ambient) Operational: -25°C to 55°C
Operational with P/N:407090-001 heater option: -60°C to 55°C
Storage: -40°C to 85°C
FREQUENCY BAND
Rx 19.2 to 20.2 GHz
Tx 29.0 to 30.0 GHz
ANTENNA CABLE
ACU to ADU cable Single 50 ɏ coax cable for Rx, Tx and antenna power. 50 ɏ N-Connector
ABOVE DECK UNIT (ADU)
Antenna type, pedestal 3-axis stabilised tracking antenna with integrated GNSS (GPS, GLONASS, Beidou)
Antenna type, reflector system Reflector/sub-reflector, ring focus
Transmit Gain 47.5 dBi typ. @ 29.5 GHz (excl. radome)
Receive Gain 44.0 dBi typ. @ 19.7 GHz (excl. radome)
System G/T 20.1 dB/K typ. @ 19.7 GHz, at ш10° elevation and clear sky (incl. radome)
LNB GX Ka single band LNB
BUC output power 5 Watt or 10 Watt
EIRP 5 Wш53.5 dBW (incl. radome)
10 W: ш57.1 dBW (incl. radome)
Tracking Receiver Internal “all band/modulation type” including e.g. power, DVB-S2, GSC and modem
RSSI
Polarisation Circular Cross-Pol (Inmarsat GX, TX: RHCP, RX: LHCP)
Elevation Range -25° to +125°
Cross Elevation +/-42°
Azimuth range Unlimited (Rotary Joint)
Ship motion, angular Roll +/-25° (6 sec), Pitch +/-15° (5 sec), Yaw +/-10° (8 sec)
Ship, turning rate and acceleration 15°/S and 15°/S2
ADU motion, linear Linear accelerations +/-2.5 g max any direction
Satellite acquisition Automatic - with or without Gyro/GPS Compass input
Humidity 100%, condensing
Rain / IP class EN60945 Exposed / IP56
Wind 80 kt. operational 110 kt. survival
Ice, survival 25 mm / 1”
Solar radiation 1120 W/m2 to MIL-STD-810F 505.4
Compass safe distance 1.0 m / 40” to EN60945
Maintenance, scheduled None
Maintenance, unscheduled All electronic, electromechanical modules and belts are replaceable through hatch
Built In Test Power On Self Test, Person Activated Self Test and Continuous Monitoring w. error
logging
Dimensions Height: H 150 cm / 58.9”
Diameter: Ø 130 cm / 51.3”
Weight 126 kg / 276 lb.
ANTENNA CONTROL UNIT (ACU)
Dimensions 1U 19” rack mount
HxWxD: 4.4 x 48 x 33 cm
HxWxD: 1.75” x 19” x 13”
Weight 4.5 kg / 10 lb.
Humidity EN60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.3m / 12” to EN60945
Interfaces 1 x N-Connector for antenna Z&ĂďůĞ;ϱϬɏͿ with automatic cable loss compensation
2 x F-ŽŶŶĞĐƚŽƌƐ;ϳϱɏͿĨŽƌZdžĂŶĚddžƚŽŵŽĚĞŵ
1 x RS-422 (modem control)
1 x RS-232 (modem control)
1 x NMEA 0183 (RS-422 or RS-232) for Gyro/GPS Compass input and external GPS
1 x RJ-45 Ethernet (modem control)
3 x RJ-45 Ethernet (service and user)
1 x AC power input
1 x Grounding bolt
