98-141779-G Appendix A: Technical specifications A-5
AAAA
A.3 Patents
Input power 100 - 240 VAC, 175 W typical, 370 W peak
Modem control Generic, OpenAMIP, Custom protocol
User interface Webserver, OLED display (red), 5 pushbuttons, 3 discrete indicator LEDs and On/Off
switch
Temperature control Built-in fan
Blocking zones Programmable, 8 zones with azimuth and elevation
Real-time blocking map recorder
Remote access and management HTTPS, SSH, SNMP Traps, Syslog, CLI, Diagnostic, Statistic
GX MODEM UNIT (GMU)
Modem type SAILOR Global Xpress modem
Dimensions 1U 19” rack mount
HxWxD: 1.75” x 19” x 13”
Weight 3.5 kg / 7.7 lb
Humidity EN60945 Protected, 95% (non-condensing)
IP class IP30
Compass safe distance 0.4 m / 16” to EN60945
Interfaces 2 x F-Connectors ;ϳϱёͿĨŽƌZdžĂŶĚ Tx to ACU
1 x RJ-45 Ethernet for control and user data
1 x RS-422 (Modem Control)
1 x RS-232 (Modem Control)
1 x RS-232 Modem console
1 x AC power input
1 x Grounding bolt
Input power 100 - 240 VAC, 90 W peak, 30 W typical
Modem interface control OpenAMIP, RS-422 and RS-232
User interface Webserver, On/Off switch and power LED
Temperature control Built-in fan and heater
Patent application number Description
11749202.5;
10-2013-7008607; 13/819,621
An assembly comprising a movable and brakable/dampable part and a
method for braking a movable part
PCT/EP2012/063849 Combined antennas without switch
Currently applying Reflector with enforcement ring
Table A-1: Patents
