98-141779-G 3-1
Chapter 3
3333
Installation 3
This chapter has the following sections:
• What’s in the box
• Site preparation
• Installation of the ADU
• Installation of the ACU
• Installation of the modem
• To connect the ADU, ACU and modem
3.1 What’s in the box
3.1.1 To unpack
Unpack the modem, ADUand ACU. Check that the following items are present:
• SAILOR 7009C/G/K/L ADU with 4 lifting brackets (already mounted)
• Accessory kit for SAILOR 7009C/G/K/L ADU:
• Package with cable glands (2 sizes), bolts and washers
• SAILOR 7016C ACU
• Accessory kit for SAILOR 7016C ACU:
• NMEA multi-connector
• RJ45 patch cable (0.5 m)
• Coax cable F-F, low loss, 75 Ohm (2 pcs)
•RJ45 patch cable (2m)
• Power cable (1x230 VAC)
• SAILOR 7023A GMU
• Accessory kit for SAILOR 7023A GMU including
• Wiecon 3.5 mm spacing, 4 pol connector for cable
• RJ45 patch cable (1 pce)
• Power cable 230 VAC
• RS-232/RS-422 cable (2 pcs)
3.1.2 Initial inspection
Inspect the shipping cartons and wooden box immediately upon receipt for evidence of
damage during transport. If the shipping material is severely damaged or water stained,
request that the carrier's agent be present when opening the cartons and wooden box. Save
all box packing material for future use.
