SAILOR 100 GX system
2-2 Chapter 2: Introduction 98-141779-G
2.1.1.1 SAILOR 100 GX features
Single 50 Ohm coax cable between ADU and below deck equipment.
One-Touch Commissioning.
GX-R2 support.
Easy conversion from GX to GX-R2.
Gyro-free operation.
SNMP traps and remote syslog support.
Secure connection, HTTPS and SSH
Remote access using SAILOR FleetBroadband over WAN.
Remote or local simultaneous software update of the GMU, ADU and ACU using a PC
and Internet browser.
Full remote control and troubleshooting with built-in test equipment (BITE).
ACU with 4 x LAN, NMEA 0183, RS-232 and RS-422.
Global RF configuration.
GMU with 8+2 LAN, RS-232 and RS-422 and I/O connector.
No scheduled maintenance.
High Power amplifier for Inmarsat High End Off Shore airtime service.
Figure 2-2: ADU, ACU and GMU
Above Deck
Unit (ADU)
Antenna Control Unit (ACU)
GX Modem Unit (GMU)
