USER MANUAL
to enter number; if a target object is detected moving from side A to side B, the system
will count 1 to exit number.
5.
Use your mouse to click 2 points in the camera picture to draw a virtual line.
6.
Click
Save
to save your settings.
7.
If you want to modify the position or length of the line, click the red box in the line, the
color of the line will be changed to red color. Click and hold the left button of your mouse
to move the line, or drag the terminals to modify the length or position of the line.
8.
If you want to remove one of the lines from the camera picture, click the red box in the
line and then click
Remove
button. Click
Remove All
will delete all lines.
5.4.1.6 HM (Heat Map)
Automatically regular detect and count the movement of objects in the monitoring area. The
frequency of people flows will be identified by different colors.
Switch:
Check the box to enable LCD function.
Click
Setup
icon to configure the detection conditions.
1.
To enable the detection in
Rule Switch
.
2.
Use your mouse to click 4 points in the camera picture to draw a virtual region. The sharp
of the region should be a convex polygon. Concave polygon will be not able to save.
3.
Click
Save
to save your settings.
4.
If you want to modify the position or sharp of region, click the red box in the region, the
