Overview
2-10 HF SSB transceiver user guide
Control panel Microphone Function
9.
S'Call
Mute
The  
 
button removes normal
background noise until a selcall is
received. When selcall mute is selected,
the indicator at the top left of the button is
on.
10.
Scan
Scan
8
The 

button starts and stops the
transceiver scanning selected channels for
incoming calls.
11.
Emgcy
Call
The  
 
button sends an emergency
selcall depending on how you set up the
transceiver.
12.
The microphone socket.
13.
USB/LSB
The 

button selects upper or lower
sideband (USB or LSB). The display
indicates the selected sideband.
14.
F1
F1
2
The 

button performs different functions
depending on the transceiver’s operating
mode. The bottom left position of the
transceiver display shows the current
function.
15.
Mute
9
The 

button silences the transceiver
until a call is received. It switches the mute
on in whichever mute setting (selcall or
voice mute) was last selected on the
control panel.
