e-mark marking device Chapter 3 Description
CODI Standard 1.0 Page 17 of 61
Operating and Maintenance Manual
3.2 Components
The following section contains an overview main components of the e-mark:
Fig. 3: e-mark parts
Main constituent elements
No.
Description
No.
Description
(1)
Docking station
(4)
Battery
(2)
Electronics compartment
(5)
Ink cartridge
(3)
Cover
1
3
4
5
2
