Colop e-mark - Technical Specifications and Dimensions

e-mark marking device Chapter 3 Description
CODI Standard 1.0 Page 20 of 61
Operating and Maintenance Manual
3.4 Technical specifications and dimensions
Technical specifications of the e-mark
Weight
224.5 g (approx. 450 g incl. packaging)
Dimensions L x W x H
111.2 x 76.5 x 72.7 mm
Rechargeable battery (3 cells, each 3.7 V)
11.1 V Li-Ion with min. 600 mAh
Power consumption while operation with
battery supply
Max. 10 W
Power consumption while battery is charging
(WIFI activated)
15 V, 400 mA
WIFI interface
WIFI IEEE 802.11bgn
USB interface
Micro USB
Optimum print speed
100 mm/s
Maximum print speed
300 mm/s
Print quality
600 dpi
Protection class
III, Extra low voltage
Mains connection charger
100-240 V, 50/60 Hz
Print head 3-colour (cyan, magenta, yellow)
COLOP 3-color Ink Cartridge C2P06AE
Storage temperature range
-40 °C to 60 °C
Operating temperature range
15 °C to 32 °C
Non-Operating humidity range
20 to 80 %
Print on absorbent surfaces such as
Plain paper, cardboard, fabric, wood, cork, dry wall,
high-gloss paper, photo paper
Range:
The range of an ink cartridge is dependent on several factors, including size and coverage of the imprints.
An ink cartridge lasts approximately 5,000 imprints (14 x 100 mm test imprint) in normal use and self-
cleaning frequencies before replacing.
The lithium ion rechargeable battery lasts for up to 5 hours of continuous printing and can be recharged
approximately 1,000 times. Battery charging takes up to 2.75 hours from 0 % to 100 %.
Fig. 6: Reference imprint 14 x 100 mm
Surfaces:
The e-mark can print directly onto a variety of absorbent flat surfaces including standard paper,
cardboard, fabric, wood, cork, dry wall, high-gloss paper, photo paper and other surfaces with special
coatings.
