e-mark marking device Chapter 3 Description
CODI Standard 1.0 Page 19 of 61
Operating and Maintenance Manual
Docking station:
Fig.5: Docking station assembly
Main components of the docking station
No.
Description
No.
Description
(1)
Docking station
(5)
Non-slip feet
(2)
Print head wiper
(6)
Protective cap to prevent print head from
drying out
(3)
Slider to extend the print head wiper
(7)
Charging socket
(4)
Opening for the on/off switch
(8)
Battery contacts
Top section
Underside
6
7
2
3
4
5
8
4
5
1
1
