Colop e-mark - Performing the Marking Process

e-mark marking device Chapter 5 Operation
CODI Standard 1.0 Page 29 of 61
Operating and Maintenance Manual
5.1 Image transfer
To transfer standard templates or customized imprints to the e-mark, refer to the software description.
Prerequisites:
If not connected by the USB cable:
 The e-mark is connected via WIFI to the mobile device (see chapter 5.7).
 The Light Guide displays a steady blue light confirming a WIFI connection.
 In the App, the WIFI symbol confirms a WIFI connection.
Or if connected by the USB cable:
 The e-mark is connected by USB cable to the computer (see chapter 5.8).
Image transfer:
Refer to the software description for details.
Acoustic and optical signals:
 During image transfer to the e-mark, the Light Guide (see chapter 5.3) flashes blue continuously
and a long signal sounds when the transfer is complete.
NOTICE
Saving the image file can take several seconds. Do not switch off the e-mark
before you hear the double beep confirming the saving process has been
successful, otherwise saving is interrupted.
Image saving:
The e-mark takes time to save the newly transferred image to the internal Flash memory. During the saving
time, the Light Guide (see chapter 5.3) displays a continuous purple flashing LED. Do not switch off the e-
mark during the saving process, otherwise the image will not be saved correctly. A brief signal sounds at
the end of the saving process.
5.2 Marking
Switch on the e-mark (in the docking station) by sliding the switch from OFF to ON. The Light Guide shows
that the e-mark is powering up (flashing green LED).
The e-mark is held in the docking station by magnets.
Switch on the e-mark by sliding the switch from the OFF to the ON position.
