ECON-4 1.4.0 Global Guide
64
Setpoint group Main PID Related FW
1.4.0
configured ECON-4 extension
module
Range [units] -
Default value ActType1 Force value NO
Step -
Comm object 7185 Related applications ALL
Setpoint visibility Always
Description
ECON-4 can be connected to various types of actuators. Setpoints of the internal actuator feedback loop are
tuned for the common actuators and predefined from the factory. Normally there is no need to change them.
The user must only choose the right Actuator type. By default the ActType 1 is chosen. Check the type of
your actuator and compare with the predefined type.
Actuator type
6 back to List of setpoints
Setpoint group Main PID Related FW
1.4.0
configured ECON-4 extension
module
Range [units] -
Default value AUTO Force value NO
Step -
Comm object 7190 Related applications ALL
Setpoint visibility Always
Description
ECON-4 must be in AUTO for normal operation. Mode MAN can be used during installation to check the
function of the actuator and linkage. If ECON-4 is in MAN mode, it sets the actuator to position Act position.
It can be switched to MAN mode only any time even engine is running. This allows measurement of
transition curve to calculate PID parameters.
ECON-4 mode
Note: ECON-4 when engine is running set the same value to setpoint Act position as position where throttle is.
It assure bump less transition.
IMPORTANT: Even Overspeed protection is active in all modes, be carefull when setting throttle
position manualy. Engine can accelerate when breaker opens or when throttle position is too
high.Make sure ECON-4 mode is in Auto positon before you leave installation.
6 back to List of setpoints
