ComAp ECON-4

ECON-4 1.4.0 Global Guide
65
Setpoint group Main PID Related FW
1.4.0
configured ECON-4
extension module
Range [units] 0.0 – 100.0 %
Default value 30% Force value NO
Step 0.1 %
Comm object 7191 Related applications ALL
Setpoint visibility Always
Description
Adjusts the actuator position in the Econ-4 Mode = MAN.
Act position
6 back to List of setpoints
Setpoint group Main PID Related FW
1.4.0
configured ECON-4 extension
module
Range [units] 500 – 10 000 Hz
Default value 6000 Hz Force value NO
Step 1 Hz
Comm object 7194 Related applications ALL
Setpoint visibility Always
Description
Frequency of the PWM signal sent to ACT+ and ACT- outputs..
PWM rate
Note: For Heinzmann actuators adjust the PWM rate to 6000 Hz. For Woodward PWM and current, GAC
actuators adjust the PWM rate to 2000Hz.
6 back to List of setpoints
Setpoint group Main PID Related FW
1.4.0
configured ECON-4 extension
module
Range [units] ± 10 V
Default value 0.00 V Force value NO
Step 0.01 V
Comm object 14375 Related applications ALL
Setpoint visibility [[[Undefined variable Specific.WinScopeOnly]]]
Description
Together with Idle Fuel value creates coordinates for first point of Speed/Fuel line. For detailed description
seesee Speed governor function in parallel mode on page 38 ECON-4 Global Guide.
SGO Bias
Note: Setpoint is active for unloaded engine.
