12.2.11.12 Setpoint: Force value 12
Group
Force value
Range [units]
[-]
Related FW
3.0
Description
This is one of the 16 setpoints reserved for using as alternative setpoints for
the force value functions. The alternative setpoint is to be assigned to a
particular force value function and renamed in GenConfig.
See also the input Force value 1.
NOTE:
It is not obligatory to use one of these reserved setpoints for a force value
function. It is possible to use also any other setpoint or value with matching
dimension and decimal resolution.
NOTE:
There isn't any relation between the default names of the force value function
blocks, associated binary inputs and the default names of the reserved
setpoints. In other words, the setpoint with default name Force value 3 is not
related to the Force value 3 function block.
12.2.11.13 Setpoint: Force value 13
Group
Force value
Range [units]
[-]
Related FW
3.0
Description
This is one of the 16 setpoints reserved for using as alternative setpoints for
the force value functions. The alternative setpoint is to be assigned to a
particular force value function and renamed in GenConfig.
See also the input Force value 1.
NOTE:
It is not obligatory to use one of these reserved setpoints for a force value
function. It is possible to use also any other setpoint or value with matching
dimension and decimal resolution.
NOTE:
There isn't any relation between the default names of the force value function
blocks, associated binary inputs and the default names of the reserved
setpoints. In other words, the setpoint with default name Force value 3 is not
related to the Force value 3 function block.
