Point 11 - Configuration upload
Current archive is download to USB key (Name = SN_YYMMDDHHMM).
New configuration is uploaded into the controller without the change of the firmware
History record "USB key CFG upload" is made
Confirming file (.txt) on USB key is made (Name = SN_YYMMDDHHMM)
Content: Serial number, Year/Date/Time, Upgrade to the FW "Name of the new CFG" successful.
Confirmation pop-up message: "CFG upgrade success"
Firmware and configuration upload
Point 1 - controller detects that USB Flash Drive has been inserted.
If the communication via USB B is running controller will not detect the USB memory key.
On the other hand if the USB memory key was detected, communication via USB B port is not possible.
Point 2 - controller is in OFF mode
All operations with USB memory key are possible only in OFF mode
Point 6 - conditions for new firmware and configuration upload
The new configuration has been detected. Also there is firmware file compatible with detected new
configuration
Detection is based on name of configuration - required name: "InteliMains210-Genset name-
M.N.P.B.aig3" and on name of firmware - required name: "InteliMains210-M.N.P.B.bin"
There can be only one configuration file
There can be stored more firmwares on the USB key. Controller automatically select the compatible
firmware with highest version.
Point 7 - Pop-up message
Confirmation of configuration and firmware upload
Point 8 - Configuration and firmware upload
Current archive is download to USB key (Name = SN_YYMMDDHHMM).
New firmware is uploaded into the controller
New configuration is uploaded into the controller
History record "USB key FW and CFG upload" is made
Confirming file (.txt) on USB key is made (Name = SN_YYMMDDHHMM)
Content: Serial number, Year/Date/Time, Upgrade to the FW "Name of the new FW" successful,
Upgrade to the FW "Name of the new CFG" successful.
Confirmation pop-up message: "FW and CFG upgrade success"
Configuration download
Point 1 - controller detects that USB Flash Drive has been inserted.
If the communication via USB B is running controller will not detect the USB memory key.
On the other hand if the USB memory key was detected, communication via USB B port is not possible.
