InteliMains 210 Global Guide
171
Setpoint group Process Control Related FW 2.0.0
Range [units] 0 .. 32 000 [kW]
Default value 1 000 kW Alternative config NO
Step 1 kW
Comm object 8775 Related applications MCB, MGCB, BTB
Description
Required total load of the gen-set group in parallel to mains operation in baseload mode (setpoint #System
Load Control PTM (page 170) = Baseload).
#System BaseLoad
6 back to List of setpoints
Setpoint group Process Control Related FW 2.0.0
Range [units] 0,60 .. 1,20 [-]
Default value 1,00 [-] Alternative config NO
Step 0,01 [-]
Comm object 8776 Related applications MCB, MGCB, BTB
Description
Required gen-set power factor when the group of gen-sets is running parallel to the mains. The PF is
regulated locally in each controller by PF control regulation loop, VARsharing is not active.
#System Power Factor
6 back to List of setpoints
Subgroup: Mains coupling
Setpoint group
Process
Control
Related FW 2.0.0
Range [units] Enabled / Disabled [-]
Default value Disabled Alternative config NO
Step [-]
Comm object 11037 Related applications MCB, MGCB, BTB
Description
Setpoint adjusts behavior of BTB in systems where mains is present on both sides of bus.
Enable - BTB can be closed when there is mains on both sides
Disable - BTB cant be closed, when there is mains on both sides
Note: Passive phase/voltage check is performed before mains coupling.
Mains Coupling
6 back to List of setpoints
