ComAp InteliMains 210 BTB User Manual

InteliMains 210 Global Guide
245
General Analog Input 20
Setpoint group General Analog Inputs Related FW 2.0.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 9316 Related applications MCB, MGCB, BTB
Description
Warning or history threshold level for AIN PROT20 (PAGE 483).
Note: These setpoints are used only if LAI AIN PROT20 (PAGE 483) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 20 Wrn
6 back to List of setpoints
Setpoint group General Analog Inputs Related FW 2.0.0
Range [units] the range is defined by analog sensor curve
Default value
the value is defined by
analog sensor curve
Alternative config NO
Step the step is defined by analog sensor curve
Comm object 9317 Related applications MCB, MGCB, BTB
Description
Shutdown or BOC threshold level for AIN PROT20 (PAGE 483).
Note: These setpoints are used only if LAI AIN PROT20 (PAGE 483) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 20 Sd
6 back to List of setpoints
Setpoint group General Analog Inputs Related FW 2.0.0
Range [units] 0 .. 900 [s]
Default value 0 s Alternative config NO
Step 1 s
Comm object 9318 Related applications MCB, MGCB, BTB
Description
Delay for AIN PROT20 (PAGE 483).
Note: These setpoints are used only if LAI AIN PROT20 (PAGE 483) is adjusted to required protection
type. Otherwise these setpoints are useless.
Analog Protection 20 Delay
6 back to List of setpoints
