InteliMains 210 Global Guide

402

LBI: B

Related FW 2.0.0 Related applications MCB, MGCB, BTB

Comm object 9999

Description

This binary input is for general input function used as alarm.

Monitoring Binary input is not used for protection or any other function. Signal is only

monitored.

HistRecOnl Binary input is not used for protection. Only history record is made if binary input is

active.

AL Indic Binary input is not used for protection. Only alarmlist record is made if binary input

is active.

Wrn Binary input is used for warning protection only.

BO Breaker open protection without reset. Protection is signalized with red LED status

but the alarm is not in alarm list.

BOR Breaker open protection with reset. Protection is signalized with red LED status

and alarm is recorded in alarm list.

FLS Sensor fail protection.

Protection types

BIN Protection 1
