InteliMains 210 Global Guide
524
Other type
Alarm Type BOR
Alarmlist message BOR + Name of analog input
Alarm evaluated All the time
Related applications MCB, MGCB, BTB
Description
This alarm indicates that the value of general analog protection is out of BOR
protection limit.
BOR AIN Prot
6 back to List of alarms level 2
Alarm Type BOR
Alarmlist message BOR + Name of binary input
Alarm evaluated All the time
Related applications MCB, MGCB, BTB
Description
Binary input also can be adjusted like alarm. In this case message in alarmlist
contains prefix - BOR and binary input name. This alarm occurs, when appropriate
binary input is active.
BOR BIN Protection
6 back to List of alarms level 2
Alarm Type BOR
Alarmlist message BOR Current Unbalance
Alarm evaluated All the time
Related applications MCB, MGCB, BTB
Description
This alarm evaluates the unbalance of the phase currents, i.e. the difference
between highest and lowest phase current at any given time. The following
setpoints are related to it:
Current Unbalance (page 188) adjusts the maximum allowed difference
between the highest and lowest phase current at any given time.
Current Unbalance Delay (page 188) adjusts the alarm delay.
Current Unbalance
6 back to List of alarms level 2
Alarm Type BOR
Alarmlist message BOR Overcurrent IDMT
Alarm evaluated All the time
BOR Overcurrent IDMT
