InteliMains 210 Global Guide
553
Number
Up to 8, non-isolated
Close/Open indication
0-2 VDC close contact
>6 VDC open contact
Binary inputs
Number
Up to 8 , non-isolated
Max. current
0,5A
Switching to
positive supply terminal
Binary outputs
Number of inputs
2
Nominal input current
1A/5A
Load (CT output impedance)
< 0,1
Max measured current from CT
10 A
Current measurement
tolerance
2% from Nominal current
Max peak current from CT
150 A / 1 s
Max continuous current
10 A
Current measuring input
Firmware upgrade
Download the newest FWof module from ComAp website (in form of PSI file or installation package)
Instal package to computer or open PSI to instal it into InteliConfig
Plug the module into the controller and power the controller on.
Open a connection with controller via InteliConfig
Go the menu Tools -> Firmware upgrade, select the Plug-in modules tab and select the appropriate firmware
you want to program into the module (in InteliConfig).
Press the OK button to start upgrade of firmware.
The firmware update process may be performed via any kind of connection including connection via the same
module in which the firmware is to be updated. The connection is reestablished again automatically when the
update process is finished.
8.3.2 CAN modules
Extension modules 554
The available extension CAN modules are:
Inteli AIN8 - extension CAN module with 8 analog inputs
Inteli IO8/8 - extension CAN module with 8 binary inputs, 8 binary outputs and 2 analog outputs
this CAN module can be switched to Inteli IO16/0 - extension CAN module with 16 binary inputs and 2
analog outputs
