ComAp InteliMains 210 BTB User Manual

InteliMains 210 Global Guide
554
Slot Inteli AIN8 Inteli AIN8TC Inteli IO8/8 Inteli IO16/0 IGL-RA15 IGS-PTM Inteli AIO9/1
1
1
3
4
5
Supported combinations of modules
IMPORTANT: In slot 3, 4 and 5 CAN modules Inteli IO8/8 and Inteli IO16/0 are supported without
analog outputs. Analog outputs of these CAN modules are supported only in slot 1 and 2.
It is possible to add up to 80 binary inputs or up to 68 binary outputs or up to 32 analog inputs on CAN modules.
Extension modules
Inteli AIN8 554
Inteli IO8/8 560
IGS-PTM 567
Inteli AIN8
Inteli AIN8 module is extension module equipped with analog inputs. Inteli AIN8 module is connected to
controller by CAN1 bus.
Image 8.171 Inteli AIN8
