InteliMains 210 Global Guide
555
Image 8.172 Inteli AIN8 dimensions
Note: All dimensions are in mm.
Terminals
Analog input 8 analog Inputs
CAN CAN1 line
Power Power supply
CAN LED Tx, Rx Indication transmitted or received data
Status LED LED indication of correct function
CAN terminator Terminating CAN resistor (active in position “ON” - switch both switches)
