InteliMains 210 Global Guide
566
Note: Limit of analog ground (AGND) is 100mA.
IMPORTANT: Terminator for analog output has special analog ground (AGND), which must not be
connected to the GND.
Technical data
Power supply 8 to 36 V DC
Current consumption 35 mA at 24 V ÷ 100 mA at 8 V
Interface to controller CAN1
Protection IP20
Storage temperature - 40 °C to + 80 °C
Operating temperature - 30 °C to + 70 °C
Dimensions (WxHxD) 110x110x46 mm (4,3”x4,3”x1,8”)
Weight 240 grams
General data
Number of channels 2
Voltage
Range 0-10 V
Accuracy: ± 20 mV + ±0,5 % of actual value
Imax 5 mA
Current
Range: 0-20 mA
Accuracy: ± 100 µA + ±0,5 % of actual value
Rmax 500 Ω
PWM
Level 5 V
Frequency - adjustable 200÷2400 Hz
Imax 20 mA
Analog outputs
Number of channels 8 for Inteli IO8/8, 16 for Inteli IO16/0
Input resistance 4400 Ω
Input range 0 to 36 V DC
Switching voltage level for open contact
indication
0 to 2 V DC
Max voltage level for close contact indication 6 to 36 V DC
Binary inputs
Number of channels 8 for Inteli IO8/8, 0 for Inteli IO16/0
Max current 500 mA
Max switching voltage 36 V DC
Binary outputs
