InteliMains 210 Global Guide
574
Press Lamp test to switch to the next LED color adjusting
Continue to adjust all LEDs color
After LED15 color adjusting press three times Lamp test
Note: If there is no operator action during address setting, color adjusting or timeout setting, the unit returns to
normal operation without changes saving.
Status LED
The signals LEDs are handled like binary outputs. It means all what can be configured to binary outputs can be
also configured to the LEDs of IGL-RA15.
LEDstatus Description
Lights Configured logical output is active on the controller
Dark green LED Configured logical output is not active on the controller
Dark yellow or red LED
Configured logical output is not active on the controller and horn reset was
pressed.
Yellow or red LED blinks
Configured logical output is not active on the controller and horn reset was still
not pressed.
Power LED
LEDstatus Description
Blinking green The unit is OK and the communication to the master controller is OK.
Blinking red The unit is OK, but the communication to the master controller is not running.
Blinking yellow EEPROM check not passed OK after power on
Yellow Horn timeout or controller address adjustment
Horn setting
The horn output is activated if any of red or yellow LED is on. Output is on until pressing Horn reset or horn
timeout counts down. The timeout can by set by following steps:
Switch to programming mode (Hold the Horn reset and Lamp test when unit is powering on). Status led is
yellow
Press Lamp test fifteen times
Set the horn timeout by pressing Horn reset.
The number of green luminous LEDs means timeout in 10 s (any for disabling horn output, 1 for 10s
timeout, 2 for 10s timeout, 15 for disabling horn timeout).
Press Lamp test two times
Note: If there is no operator action during address setting, color adjusting or timeout setting, the unit returns to
normal operation without changes saving.
The horn is activated if:
Some of red or yellow LED lights up or
At the end of the extended lamp test. See chapter Lamp and horn test (page 575)
The horn can be silenced:
