InteliMains 210 Global Guide
83
Image 5.18 Power management based on absolute load reserve
Example: An example of absolute power management is shown on the figure below. There are three gen-
sets with following choice of setpoints:
Gen-set
Nominal
power
Power
management
#Power
management
mode
Priority
#Priority
Auto
Swap
#Starting
Load
Reserve X
#Stopping
Load
Reserve X
Gen-set
#1
200 kW ENABLED ABS (kW) 1 DISABLED 100 kW 125 kW
Gen-set
#2
500 kW ENABLED ABS (kW) 2 DISABLED 100 kW 125 kW
Gen-set
#3
1 000 kW ENABLED ABS (kW) 3 DISABLED 100 kW 125 kW
