Overview
12 Comdial October, ‘03
The maximum system configuration is 16 CO lines, 56 extensions (48 digital and 8 analog) and 8
voice processing channels.
Device
Name
Part # Characteristics
KSU1 7201 8 digital extension ports.
4 analog device ports.
4 CID-ready CO line ports.
2 music source inputs, can be assigned as desired to CO lines for hold music/
messages.
1 power failure port (CO line 1).
1 control contact (LBC, Gate, External Page Control).
1 external paging equipment interface.
2 serial ports.
PC-DBA programming.
SMDR (Station Message Detailed Recording).
OPTIONAL EQUIPMENT
KSU2 7202 Used to expand the system capacity beyond KSU1 limits.
8 digital extension ports
4 CO line ports
1 power failure port (CO line circuit 1).
DPM8 7220 Digital Port Module - 8 circuit.
Installs into KSU1 or KSU2.
APM4 7230 Analog Port Module - 4 circuit.
Installs into KSU1 or KSU2.
COM4 7210 CO line Module - 4 circuit with one power failure port on first CO line
circuit.
Installs into KSU1 or KSU2.
MDM 7249 Modem Module, for use with off-site programming.
Installs into KSU1 only.
AAM 7240 Automated Attendant Module.
4 port, one menu for routing.
10 announcements for various caller greetings. Installs into KSU1 only.
CO DX
FLASH
7271C Flash-based, 4-port Voice Mail (Corporate Office DX) with Auto Attendant.
1.5 hours storage and 100 mailboxes.
CO DX
HD
7270C Hard Drive-based, 4-port Voice Mail (Corporate Office DX) with Auto
Attendant and on-board modem.
100 hours storage and 100 mailboxes.
7272 4 port expansion to 7271C or 7270C.
