1.15 Specifications
1.15.1 CURRENT DRAW
Use this chart to calculate the Amphour requirements of the DX-80 system based upon its configu-
ration. This information is typically used to apply UPS battery requirements.
Component Current Draw
(Amps) @ 117 VAC
Quantity Extended
Total Amps
KSU1 (7201) 0.18A 1 0.18A
KSU2 (7202) 0.17A 1 max.
COM4 (7210) 0.02A 2 max.
DPM8 (7220) 0.01A 4 max.
APM4 (7230) 0.08A 3 max.
MDM (7249) 0.01A 1 max.
AAM (7240) 0.01A 1 max.
7271C 0.02A 1 max.
7270C 0.01A 1 max.
DET (7260-00) 0.016A 48 max.
DSS (7266-00) 0.016A 12 max.
Station wire:
per DET, DSS,
and IST
0.02A every 100 ft. of
24AWG
?
Multiply the unit times the quantity installed in the subject
application (site) and add the right column for the total current
draw (Amps) @ 117VAC for this site.
