October, ‘03 Comdial 35
DX-80 Installation & Maintenance
1.15.6 WIRING DATA
1.15.7 SIGNALING (CENTRAL OFFICE-PSTN) DATA
7266-00 DSS Console – Black L
W
H
241 mm
202 mm
93 mm
9.5 in.
8 in.
3.75 in.
1.7Kg
Maximum Cable Length
DET (distance measures in linear feet of
cable from KSU to DET)
26 AWG - 255m (850 ft.)
24 AWG - 425m (1416 ft.)
22 AWG - 700m (1983 ft.)
Standard Single Line Telephone (distance
measures in linear feet of cable from KSU
to IST)
26 AWG - 195m (650 ft.)
24 AWG - 340m (1133 ft.)
22 AWG - 476m (1586 ft.)
Dialing Specifications
DTMF Dialing Mode
Frequency deviation:
Rise time:
Duration of DTMF signal:
Inter-digit time:
VM Port DTMF duration:
VM Port Inter-digit time:
+ 1%
3ms
programmable 50-150ms (70ms default)
programmable 50-150ms (70ms default)
programmable 60-150ms (120ms default)
programmable 60-150ms (120ms default)
Pulse Dialing Mode
Pulse dial rate:
Pulse Make/Break ratio:
10 pulses per second
60/40
Unit Specifications
