Comen N Series - Parameter Board

Principle Introduction
4
U7
WIFI module socket
J14
Parameter board connection socket
Table 3-3
3.2.4 Parameter Board
Chart 3-5
Socket
Description
Working voltage
J1
Parameter board power supply,
communication interface
12V，5V，3.3V
J38
COMEN NIBP air pump socket
/
J39
COMEN NIBP air valve socket
/
J46
COMEN SPO2/NELLCOR SPO2 power
supply, communication socket
J47
COMEN SPO2/NELLCOR SPO2 signal
wire socket
Table 3-4
Chart 3-6
