lights of ST status indicator go out at the same time), the verification instrument displays “HELLO”, press
S+SU key of the verification instrument to make the project indicator “7” light up, input 0.5 mV, input 30
bpm, adjust the output signal of the verification instrument, if the output HR value is 15 bpm in adult mode,
the display result of the monitor should be within the following range: 14-16 bpm; if the output HR value is
350 bpm in pediatric/newborn mode, the display result of the monitor should be within the following range:
347-353 bpm.
6.4 TEMP Test
Tools required:
Resistance box
Follow this procedure to perform the test:
Use the resistance box for testing, access the resistance box at the TEMP interface of the monitor, change the
resistance value, the temperature of the corresponding TEMP channel should change accordingly. The results
should be displayed in the following range: 36.9 to 37.1°C; the resistance value and temperature should be in
accordance with the table below:
Body temperature value (℃)
CY-F1 resistance value (Ω)
YSI resistance value (Ω)
37
6,017 (6,000.5-6,039.3)
1,351
Table 6-1
6.5 SpO
2
Test
Tools required:
SpO
2
probe, SpO
2
simulator
Follow this procedure to perform the test:
1) Connect the main unit and the SpO
2
simulator, select the type of SpO
2
(FLUKE Index2 setting method:
Press “more” key to select “Main Menu 2” → Press “MAKE” key to select the type of SpO2 “Nellcor”
or “Masimo” → Press “esc” to exit → Press “more” key to select “Main Menu 1” → Press “SIM” key
and then press “MAN” key to enter into the interface of SpO
2
measurement, and then adjust the set
value of SpO
2
by pressing “O
2
+” or “O
2
-”.
2) Press “BPM+” or “BPM-” to adjust the SpO
2
pulse rate to simulate 90%, the instrument display should
be within 88% to 92%.
3) Using a pulse oximetry simulator to simulate 35%; parameter values should be shown on the
instrument; precision is not necessary.
6.6 CO
2
Test
Tools required:
T-shape connector, a steel gas cylinder with 6 ± 0.05% CO
2
and balance gas N
2
Follow this procedure to perform the test:
1) Connect the module to the machine.
2) Wait until the CO
2
module warmup is finished, and check the airway for leakage and perform a
leakage test as well to make sure the airway has no leakage.
3) Enter the CO
2
Menu—->CO
2
Settings—->CO
2
Zeroing.
4) Select standard 38 mmHg CO
2
, connect it to the inlet of the respiratory rhythm through a gas cylinder,
