Performance Verification, Calibration
4
connect the output of the respiratory rhythm to the inlet of the CO
2
module through a gas cylinder.
Connect the test system as follows:
Chart 6-3
1) Open the relief valve of the standard gas cylinder and use the monitor knob to enter the CO
2
menu to
select the measurement function; a range of 36 to 40 mmHg should be displayed on the monitor
interface.
