The interface of the control software is showed as below:
Please set the parameters of COM number, bound rate, data bit, stop bit and the parity bit
correctly, then the RS232 commands can be sent in Command Sending Area.
Parameter configuration area
Monitoring area, show the commands
and its feedback information.
Command sending area
