Comm-Tec MTX88M-N - Uh & 4 O-Uh

Modular Matrix Switcher
Comm-tec Srl 67 www.comm-tec.it
Resolution
Up to 1080P@60Hz
Bandwidth
6.75 Gbps
Standard
HDMI 1.3 and HDCP 1.2
EDID and DDC
Supports Extended Display Identification Data (EDID)
and Display Data Channel (DDC) data
8.2.6. 4I-UH & 4O-UH
4I-UH
Input
(4) HDMI, (4) Audio
Input Connector
(4) Female 19-pin type-A HDMI,
(4) 3-pin pluggable terminal block
Input Level
T.M.D.S. 2.9V~3.3V
Input Impedance
75Ω
Frequency Response
20Hz～20K Hz
4O-UH
Output
(4) HDMI, (4) Audio
Output Connector
(4) Female 19-pin type-A HDMI,
(4) 3-pin pluggable terminal block
Output Level
T.M.D.S. 2.9V~3.3V
Output Impedance
75Ω
Frequency Response
20Hz～20K Hz
General
Gain
0dB
Resolution
Up to 4Kx2K
Transmission Distance
1080P≤70m, 4Kx2K ≤ 40m
SNR
>70dB@ 100MHz-100M
Return Loss
<-30dB@ 5KHz
Audio Signal Format
Embedded HDMI audio: PCM, Dobly Digital, DTS, DTS-
HD
Analog audio: PCM
Standard
HDMI 1.4 and HDCP 1.4
EDID
Support manual EDID management
