6.3.17. 4O-DS Output Card Command
Command
Description
Feedback
USER/O/[x]:0201%;
Set the output [x] to YPbPr signal.
0201%
USER/O/[x]:0202%;
Set the output [x] to VGA signal.
0202%
USER/O/[x]:0203%;
Set the output [x] to C-VIDEO signal.
0203%
USER/O/[x]:0800%;
Set the resolution of output [x] to
720x480i@60Hz.
Resolution
Ou01 720x480 I
USER/O/[x]:0801%;
Set the resolution of output [x] to
720x576i@50Hz.
Resolution
Ou01 720x576 I
USER/O/[x]:0802%;
Set the resolution of output [x] to
720x480P@60Hz.
Resolution
Ou01 720x480 P
USER/O/[x]:0803%;
Set the resolution of output [x] to
720x576p@50Hz.
Resolution
Ou01 720x576 P
USER/O/[x]:0804%;
Set the resolution of output [x] to
1280x720P@60Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0805%;
Set the resolution of output [x] to
1280x720P@59Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0806%;
Set the resolution of output [x] to
1280x720P@50Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0807%;
Set the resolution of output [x] to
1280x720P@30Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0808%;
Set the resolution of output [x] to
1280x720P@25Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0809%;
Set the resolution of output [x]
to1280x720P@24Hz.
Resolution
Ou01 1280x720 P
USER/O/[x]:0810%;
Set the resolution of output [x]
to1920x1080i@60Hz.
Resolution
Ou01 1920x1080I
USER/O/[x]:0811%;
Set the resolution of output [x]
to1920x1080i@59Hz.
Resolution
Ou01 1920x1080I
USER/O/[x]:0812%;
Set the resolution of output [x]
to1920x1080i@50Hz.
Resolution
Ou01 1920x1080I
USER/O/[x]:0813%;
Set the resolution of output [x]
to1920x1080P@60Hz.
Resolution
Ou01 1920x1080P
USER/O/[x]:0814%;
Set the resolution of output [x]
to1920x1080P@59Hz.
Resolution
Ou01 1920x1080P
USER/O/[x]:0815%;
Set the resolution of output [x] to
1920x1080P@50Hz.
Resolution
Ou01 1920x1080P
USER/O/[x]:0816%;
Set the resolution of output [x] to
1920x1080P@30Hz.
Resolution
Ou01 1920x1080P
